802BT/802R Video Test Generator User Guide 71

The following table describe the default DCS priority scheme for horizontal sync.

The following table describe the default DCS priority scheme for vertical sync.

To enable the legacy DCS priority scheme:

1. Turn off the generator.

2. Hold down the Step and DCS keys while starting the generator.

The generator will remain in this mode through subsequent power cycles until the

generator is re-initialized or reset with the “No special modes” command (hold down

ACS+DCS+DSS while starting the generator).

OUTG SSST HSPG HS Output HS Polarity

0 Do not care Do not care No signal Do not care

1 Do not care 0 No signal Do not care

Do not care 8 (DPMS – OFF) Do not care No signal Do not care

1 9 (DPMS – SUS-

PEND)

Do not care Horizontal Sync HSPP

1 10 (DPMS –

STANDBY)

Do not care No signal Do not care

1 1, 3, 5, 7, or 11 1 Horizontal Sync HSPP

1 2, 6, or 11 (DCS) 1 Composite Sync CSPP

OUTG SSST VSPG VS Output VS Polarity
