Quantum 4FRONT User Manual

13Rev.A/100217
A1a
A1b
*B1
C1
D1
E1
F1
G1
H1
I1
J1
K1
L1
M1
N1
O1
P1
Q1
R1
S1
T1
REF #
CTL143976
CTL143977
FRMASMB10617
DGN124309
DGN154742
ELE144006
ELE124312
DGN124307
DGN124336-PPK3
DGN124336-POR6
DGN124336-PGN7
DGN124336-PGN8
DGN124336-PBU10
DGN124336-PPR5
DGN124336-PSL3
DGN124336-PSL7
DGN124336-PWH2
DGN124336-PYL3
DGN124336-PRD1
DGN124336-PBU9
DGN124336-PBK1
PART #
EXPANDABLE CONTROLLER W/ JOYSTICK AND LCD COLOR
DISPLAY, Q-LOGIC 3, 4-KEY, (CURTIS: 17949700-02-0009)
EXPANDABLE CONTROLLER W/ JOYSTICK AND LCD COLOR
DISPLAY AND LIGHTS, Q-LOGIC 3, 4-KEY, (CURTIS: 17949700-02-
0109)
JOYSTICK MOUNTING BRACKET,ASSY,CURTIS
CONTROLLER,INLINE
SPEED WHEEL,KNOB,Q-LOGIC 2,PLASTIC
JOYSTICK, KNOB, Q-LOGIC 3, 6.35MM-ID, (CURTIS: 17519114-01)
ELECTRONIC, BOTTOM HOUSING, JOYSTICK MODULE Q-LOGIC 3,
W/ BUS CABLE Q-LOGIC 3, (CURTIS: 17949366-02)
JOYSTICK GIMBLE,DIGITAL,Q-LOGIC 2
CONTROLLER SHROUD,BLACK SOFT-TOUCH PAINT,Q-LOGIC 2
CONTROLLER SHROUD,PLASTIC,PRETTY IN PINK
CONTROLLER SHROUD,PLASTIC,ORANGE CRUSH
CONTROLLER SHROUD,PLASTIC,LIME LIGHT
CONTROLLER SHROUD,PLASTIC, MILITARY GREEN
CONTROLLER SHROUD,PLASTIC,MIDNIGHT BLUE
CONTROLLER SHROUD,PLASTIC,DEEP PURPLE
CONTROLLER SHROUD,PLASTIC,GRAY STREET
CONTROLLER SHROUD,PLASTIC,SILVER BULLET
CONTROLLER SHROUD,PLASTIC,WHITE SATIN
CONTROLLER SHROUD,PLASTIC,YELLOW BLAZE
CONTROLLER SHROUD,PLASTIC,RED CORVETTE
CONTROLLER SHROUD,PLASTIC,ELECTRIC BLUE
CONTROLLER SHROUD,PLASTIC,BACK IN BLACK
DESCRIPTION
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
QTY
Item is a quantity of one shown as multiple parts for assembly purposes.
Notes :
*B1
VI. Q-Logic 3 Joystick Assembly

Quantum 4FRONT Specifications

General

Drive Type	Mid-Wheel Drive
Weight Capacity	300 lbs
Foldable	No
Tire Type	Solid
Ground Clearance	3 inches
Rear Casters	6 inches
Battery Charger	8A Off-board
Seat Width	16-22 inches
Seat Depth	16-20 inches
Maximum Speed	Up to 6 mph
