18 Rev.A/100217
X. Base Mounted Light Assemblies
Bus/Multiplier
Joystick/Bus
Light Harness
Q-Logic 3
Lighting
Module
B1
Complete
Right Light Assy
Complete
Left Light Assy
To Lighting
Module
Rear Shroud Insert w/Lights
E1
Bus Cable
F1
A1b
A1a
D1
C1
