Quantum 4FRONT User Manual

17Rev.A/100217
A1
B1
C1
D1
E1
F1
G1
H1
I1
J1
K1
L1
M1
N1
O1
P1
Q1
R1
S1
T1
U1
V1
REF #
CTL143978
SCRPPH1382
ELE1611761
ELE1611815
SCRSHCS1092
ELE1611675
ELE169826
MEC167317
SCRPPH1044
MEC154602
MEC153354
SCRPPH1342
HDW155879
HAR144005
HAR144004
DWR1265H021
DWR1265H027
DWR1361H038
ELECBRK1020
SCR8110001
PLSTIE1001
PLSTIE1004
PART #
POWER MODULE, Q-LOGIC 3,120 AMP, (CURTIS: 17930700-3509)
SCREW,PPH,BLACK ZINC,M5-.8 X 25MM
HARNESS, BATTERY, FWD
HARNESS, BATTERY INTERFACE, FWD, Q-LOGIC
SCREW,SHCS,BLACK ZINC,M4-.7 X 12MM
CASTER SENSOR HARNESS ASSEMBLY, RIGHT
CASTER SENSOR HARNESS ASSEMBLY, LEFT
LIGHT MODULE BRACKET
SCREW, PAN HEAD, TYPE H, M4X0.7 X 12, FT, ISO 7045, CL 4.8, BZ
MULTIPLIER STUD MOUNT ASSEMBLY
MULTIPLIER HOLD DOWN STRAP
SCREW,PPH,BLACK ZINC,M3-.5 X 20MM
SCREW,PHILLIPS FLAT HEAD, M4-0.7 X 5MM L, ISO 7046, BLACK
ZINC, NYLON PATCH
HARNESS, BUS EXTENSION CABLE, Q-LOGIC 3, 0.410 METER,
MALE/FEMALE, (CURTIS: 17881362-01-01)
HARNESS, BASE MULTIPLIER Q-LOGIC 3, (CURTIS: 17881359-01-01)
ELECTRONIC,HARNESS,POWER TAKE OFF(PTO)/INHIBIT,CURTIS,H-
1265-021
ELECTRONIC,HARNESS,RUN PLUG,Q-LOGIC,H-1265-027
ELECTRONIC,HARNESS,RUN PLUG,SURE SEAL,SYNERGY TILT,H-
1361-038
ELECTRONIC,CIRCUIT BREAKER,70 AMP,AUTO-RESET
SCREW,SHCS,BLACK ZINC,M6-1.0 X 14MM L,ASTM A574M,W/NYLON
PATCH
TIE WRAP,BLACK,4"
TIE WRAP,BLACK,8"
DESCRIPTION
1
2
2
1
8
1
1
1
2
1
1
2
2
1
1
1
1
1
1
2
4
6
QTY
IX. Electronics Assembly — Q-Logic 3 Modules, Harnessing, and Mounting Hardware
