10 Rev.A/100217
C1
Drive Motor Assy
w/5 Spoke Hub
Right
Left
Motor Mount Assy
(Does Not include motor)
Freewheel Handle Assy
Hub Assy
I1
M1
J1
L1
K1
D1
B1a
B1b
Right
Left
A1a
A1b
H1
G1
F1
Axle Brace
Assy
E1
Drive Motor Assy
w/o Hub for use on
Units with 4 Spoke,
Knobby Tires
Right
Left
N1a
N1b
V. Drive Motor Assembly and Motor Mount Assembly
