Quantum 4FRONT User Manual

9Rev.A/100217
IV. Rear Caster Arm Assembly
A1a
A1b
B1
C1
D1
E1
F1
G1
H1
I1
REF #
MEC1700200-A
MEC1700199-A
WHL1703592
DGN168155
HDW1703195
HDW138262
NUTNYLK1011
MEC1700444
DGN168154
SCRPPH1036
PART #
CASTER ARM ASSEMBLY, RIGHT: BLACK RIM, BLACK TIRE
CASTER ARM ASSEMBLY, LEFT: BLACK RIM, BLACK TIRE
WHEEL,ASSY,FLAT FREE,9" CASTER,BLACK RIM/BLACK TIRE,D-
1202-030
FWD CASTER BUMPER
SCREW, HEX HEAD, M8X1.25 X 110, ISO 4014, CL 12.9, BZ
WASHER,FLAT,8.4 ID X 16 OD X 1.6 THK,BZ
NUT, HEX, PVTP, M8X1.25, ISO 7040, CL 5, BZ
AXLE BRACE ASSEMBLY
FWD CASTER TOP CAP
SCREW,PAN HEAD,TYPE H,M4X0.7 X 8,FT,ISO 7045,CL 4.8,BZ
DESCRIPTION
1
1
1
1
1
2
1
1
1
2
QTY

Quantum 4FRONT Specifications

General

Drive Type	Mid-Wheel Drive
Weight Capacity	300 lbs
Foldable	No
Tire Type	Solid
Ground Clearance	3 inches
Rear Casters	6 inches
Battery Charger	8A Off-board
Seat Width	16-22 inches
Seat Depth	16-20 inches
Maximum Speed	Up to 6 mph
