Chapter 1: Preface
Tape drive AC grounding inspection
4 QuantumLTO-8 HH SAS User’s Guide
7 Check the cover of the tape drive for sharp edges, damage, or
alterations that expose its internal parts.
8 Check the cover of the tape drive for proper fit. It should be in place
and secure.
9 Check the product label
on the tape drive to make sure that it
matches the voltage at your outlet.
Ta p e d r i v e A C g r ounding inspection
1 Power off the drive.
2 Disconnect all cable
s.
3 See Figure
1 which is provided for reference only. Disconnect the
power cord from its source.
4 Inspect the power cable for visible cracks
, wear, or damage.
Figure 1 AC grounding
diagram (50 Hz and 60 Hz)
