Quantum LTO-8 HH SAS User Manual

Chapter 3: Installation
Connect Power
28 QuantumLTO-8 HH SAS User’s Guide
Figure 6 Example of
connecting the SAS device to
two servers
4 Ensure the host adapter and the server are configured correctly for a
SAS bus operation. Refer to the host adapter and server
documentation for instructions.
5 If the power cord has already been installed, turn power to the tape
drive ON.
Connect Power
1 If the power cord has already been installed, skip to step 3.
2 Plug the power cord into
the rear panel (see Figure 4 on page 14),
then plug the other end into a grounded electrical outlet.
3 Power-on the unit by pressing the Po
wer button. The POST runs,
which checks all hardware except the drive head. During the POST,
the Single-character Display (SCD) flashes several segmented
1 Tape drive 4 SAS host adapter card
2 SAS connectors 5 Servers
3 SAS cables

Quantum LTO-8 HH SAS Specifications

General

Native Capacity	12TB
Compressed Capacity	30TB
Native Data Transfer Rate	300 MB/s
Buffer Size	1GB
MTBF	250, 000 hours
Media Type	LTO Ultrium 8
Interface	SAS
Compressed Data Transfer Rate	750 MB/s
Encryption	AES 256-bit
Backward Compatibility	LTO-7, LTO-6
Compatibility	LTO-8
