Chapter 2: Description
Expansion Modules
14 Scalar i6000 Planning Guide
only to the right of the control module for all configurations and the
LPM is always to the left of the CM.
For Gen 2 dual-robot configurations that include HDEMs, the library’s
maximum configuration includes up to 14 HDEMs and a single standard
expansion module to serve as the right parking module. This is because
an HDEM cannot be used as a parking module.
For the i11 release, standard expansion modules in positions 9 through
16 are no longer restricted to storage-only. Now all standard expansion
modules can accommodate the following functional units:
• I/O Management Unit on page 24
• Control Management Blade on page 24
• Fibre Channel I/O Blades on page 25
• Ethernet Expansion Blades on page 25
• Robot on page 27
• Import/Export Station on page 27 (optional)
• Tape Drives and Media on page 28 (drives are optional)
• Magazines on page 30
• Cartridges on page 31
• Power System on page 32 (required only if drives are installed; if an
expansion module contains only cartridges, all power is derived
from the control module).
