Chapter 2: Description
Operator Panel
Scalar i6000 Planning Guide 35
Network The library management interface uses an 10/100 Ethernet port on the
MCB for network connectivity. For i11, a new MCB 2.0 is available with a
1 Gb Ethernet port. This port is shared for connectivity of the remote
user interface and any encryption key management solution used for
library managed encryption.
Operator Panel
The operator panel is located on the front of the control module and
consists of indicators and a touch screen (see
Figure 15). The buttons
are for library control and power while the indicators provide library
status.
