Quantum Scalar i6000 - Front View

Chapter 2: Description
Expansion Modules
Scalar i6000 Planning Guide 17
Figure 8 Magazine and Drive
Locations in Standard
Expansion Modules with a 72-
slot I/E Station
72-slot
I/E station
magazines
DREM drive
(optional)
drive side door side
(optional in
cluste
DREM and
EM)
