Within operation temperature range, the module is 3GPP compliant.
2.
2)
Within extended temperature range, the module remains the ability to establish and maintain
functions such as SMS* and data transmission, without any unrecoverable malfunction. Radio
spectrum and radio network will not be influenced, while one or more specifications, such as Pout,
may exceed the specified tolerances of 3GPP. When the temperature returns to the normal operation
temperature levels, the module will meet 3GPP specifications again.
3. "*" means under development.
2.3. Functional Diagram
The following figure shows a block diagram of BC66 and illustrates the major functional parts.
 Radio frequency
 Baseband
 Power management
 Peripheral interfaces
Data Transmission
Features
 Single-tone: 25.5kbps (DL)/16.7kbps (UL)
 Multi-tone: 25.5kbps (DL )/62.5kbps (UL)
AT Commands
 3GPP TS 27.005/3GPP TS 27.007 AT commands (3GPP Rel. 13) and
Quectel Enhanced AT commands
Firmware Update
 Upgrade firmware via DFOTA, USB or main UART port
Real Time Clock
 Supported
Physical
Characteristics
 Size: (17.7±0.15)mm × (15.8±0.15)mm × (2.0±0.2)mm
 Weight: 1.2g±0.2g
Temperature Range
 Operation temperature range: -35°C ~ +75°C
1)
 Extended temperature range: -40°C ~ +85°C
2)
 Storage temperature range: -40°C ~ +90°C
Antenna Interface
 50Ω impedance control
RoHS
 All hardware components are fully compliant with EU RoHS directive
