Quectel BC66 - Recommended Footprint

NB-IoT Module Series
BC66 Hardware Design
BC66_Hardware_Design 51 / 59
6.2. Recommended Footprint
Figure 33: Recommended Footprint (Unit: mm)
For easy maintenance of the module, it is recommended to keep about 3mm between the module and
other components on the motherboard.
NOTE
