4.5. Antenna Requirements
To minimize the loss on RF trace and RF cable, please pay attention to the antenna design. The following
tables show the requirements on NB-IoT antenna.
Table 19: Antenna Cable Insertion Loss Requirements
Band
Requirements
LTE B5/B8/B12/B13/B17/B18/B19/B20/B26/B28
Cable Insertion loss: <1dB
LTE B1/B2/B3/B4/B25/B66
Cable Insertion loss: <1.5dB
Table 20: Required Antenna Parameters
Parameters
Requirements
Frequency Range
699MHz~2200MHz
VSWR
≤2
Efficiency
> 30%
Max Input Power (W)
50
Input Impedance (Ω)
50
4.6. RF Output Power
Table 21: RF Conducted Output Power
Frequency Band
Max.
Min.
B1
23dBm±2dB
<-39dBm
B2
23dBm±2dB
<-39dBm
B3
23dBm±2dB
<-39dBm
B4
23dBm±2dB
<-39dBm
