Quectel BG95 User Manual

LPWA Module Series
BG95&BG96 Compatible Design
BG95&BG96_Compatible_Design 9 / 47
1.
1)
GNSS function of BG96 is optional.
2.
2)
BG96 supports VoLTE (Voice over LTE) under LTE Cat M1. BG95 supports VoLTE (Voice over
LTE FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B18/B19/B20/B25/B26/
B28/B66/B71/B85
GLONASS,
BeiDou/Compass,
Galileo, QZSS
BG95-M4*
Cat M1:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B14/B18/B19/B20/B25/B26/B27/
B28/B31/B66/B72/B73/B85
Cat NB2:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B18/B19/B20/B25/B26/B28/B31/
B66/B72/B73/B85
Power Class 5 (21dBm)
GPS,
GLONASS,
BeiDou/Compass,
Galileo, QZSS
BG95-M5*
Cat M1:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B14/B18/B19/B20/B25/B26/B27/
B28/B66/B85
Cat NB2:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B18/B19/B20/B25/B26/B28/B66/
B71/B85
EGPRS:
850/900/1800/1900MHz
Power Class 3 (23dBm)
GPS,
GLONASS,
BeiDou/Compass,
Galileo, QZSS
BG95-MF
4)
Cat M1:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B14/B18/B19/B20/B25/B26/B27/
B28/B66/B85
Cat NB2:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B18/B19/B20/B25/B26/
B28/B66/B71/B85
Wi-Fi (For Positioning Only):
2.4GHz
Power Class 5 (21dBm)
GPS,
GLONASS,
BeiDou/Compass,
Galileo, QZSS
NOTES

Quectel BG95 Specifications

General

Chipset	Qualcomm MDM9205
LTE Category	Cat M1/Cat NB2
GNSS	GPS/GLONASS/BeiDou/Galileo/QZSS
Operating Temperature	-40°C to +85°C
Storage Temperature	-45°C to +90°C
SIM Interface	1.8V/3V
Dimensions	23.6 mm × 19.9 mm × 2.2 mm
LTE Cat NB2 Data Rate	127kbps (DL), 158kbps (UL)
EGPRS Data Rate	296kbps (DL), 236.8kbps (UL)
Supply Voltage Range	3.3V to 4.3V
Power Consumption	PSM: 3.2 μA
Interfaces	UART, USB 2.0, I2C, SPI, GPIO, ADC
SMS	Text and PDU Mode
Protocols	TCP/UDP/PPP
Certifications	FCC, IC, CE, RCM, PTCRB, GCF
Frequency Bands	GSM: 850/900/1800/1900MHz
