Quectel BG95 User Manual

LPWA Module Series
BG95&BG96 Compatible Design
BG95&BG96_Compatible_Design 8 / 47
Table 2: Frequency Bands and GNSS Types of BG95 and BG96 Modules
Module
Supported Bands
LTE Bands Power Class
GNSS
1)
BG96
Cat M1:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B18/B19/B20/B25
5)
/B26*/B28
LTE-TDD:
B39
Cat NB1:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B18/B19/B20/B25
5)
/B26*/B28
EGPRS:
850/900/1800/1900MHz
Power Class 3 (23dBm)
GPS,
GLONASS,
BeiDou/Compass,
Galileo, QZSS
BG95-M1
Cat M1 Only:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B14/B18/B19/B20/B25/B26/B27/
B28/B66/B85
Power Class 5 (21dBm)
GPS,
GLONASS,
BeiDou/Compass,
Galileo, QZSS
BG95-M2
Cat M1:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B14/B18/B19/B20/B25/B26/
B27/B28/B66/B85
Cat NB2:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B18/B19/B20/B25/B26/B28/B66/
B71/B85
Power Class 5 (21dBm)
GPS,
GLONASS,
BeiDou/Compass,
Galileo, QZSS
BG95-M3
Cat M1:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B14/B18/B19/B20/B25/B26/B27/
B28/B66/B85
Cat NB2:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B18/B19/B20/B25/B26/
B28/B66/B71/B85
EGPRS:
850/900/1800/1900MHz
Power Class 5 (21dBm)
GPS,
GLONASS,
BeiDou/Compass,
Galileo, QZSS
BG95-N1
Cat NB2 Only:
Power Class 5 (21dBm)
GPS,

Quectel BG95 Specifications

General

Chipset	Qualcomm MDM9205
LTE Category	Cat M1/Cat NB2
GNSS	GPS/GLONASS/BeiDou/Galileo/QZSS
Operating Temperature	-40°C to +85°C
Storage Temperature	-45°C to +90°C
SIM Interface	1.8V/3V
Dimensions	23.6 mm × 19.9 mm × 2.2 mm
LTE Cat NB2 Data Rate	127kbps (DL), 158kbps (UL)
EGPRS Data Rate	296kbps (DL), 236.8kbps (UL)
Supply Voltage Range	3.3V to 4.3V
Power Consumption	PSM: 3.2 μA
Interfaces	UART, USB 2.0, I2C, SPI, GPIO, ADC
SMS	Text and PDU Mode
Protocols	TCP/UDP/PPP
Certifications	FCC, IC, CE, RCM, PTCRB, GCF
Frequency Bands	GSM: 850/900/1800/1900MHz
