Quectel BG96 - Page 60

LPWA Module Series
BG96 Hardware Design
BG96_Hardware_Design 59 / 79
Rock Bottom
Sleep
2)
AT+CFUN=0 @Sleep State
0.8
mA
Sleep State
3)
DRX=1.28s @ Instrument
1.5
mA
DRX=1.28s @ Instrument
1.96
mA
e-I-DRX=20.48s @ Instrument
1.2
mA
e-I-DRX=20.48s @ Instrument
1.1
mA
@Real 2G Network
2.0
mA
Idle State
DRX=1.28s @ Instrument
15
mA
DRX=1.28s @ Instrument
15
mA
e-I-DRX=20.48s @ Instrument
15
mA
e-I-DRX=20.48s @ Instrument
15
mA
@Real 2G Network
15
mA
LTE Cat M1
Data Transfer
(GNSS OFF)
LTE-FDD B1 @23.31dBm
220
mA
LTE-FDD B2 @23.05dBm
208
mA
LTE-FDD B3 @23.09dBm
214
mA
LTE-FDD B4 @23.19dBm
214
mA
LTE-FDD B5 @23.22dBm
210
mA
LTE-FDD B8 @21.83dBm
203
mA
LTE-FDD B12 @21.88dBm
215
mA
LTE-FDD B13 @21.96dBm
197
mA
LTE-FDD B18 @23.04dBm
212
mA
LTE-FDD B19 @23.13dBm
211
mA
LTE-FDD B20 @23.07dBm
209
mA
LTE-FDD B25 @23.01dBm
211
mA
LTE-FDD B26 @TBD
TBD
mA
LTE-FDD B28 @22.52dBm
215
mA
