Quectel BG96 - Page 61

LPWA Module Series
BG96 Hardware Design
BG96_Hardware_Design 60 / 79
LTE-TDD B39 @TBD
TBD
mA
LTE Cat NB1
Data Transfer
(GNSS OFF)
LTE-FDD B1 @22.8dBm
170
mA
LTE-FDD B2 @22.6dBm
171
mA
LTE-FDD B3 @22.6dBm
161
mA
LTE-FDD B4 @22.6dBm
161
mA
LTE-FDD B5 @22.9dBm
156
mA
LTE-FDD B8 @22.7dBm
170
mA
LTE-FDD B12 @23dBm
170
mA
LTE-FDD B13 @22.9dBm
167
mA
LTE-FDD B18 @23.1dBm
159
mA
LTE-FDD B19 @22.9dBm
155
mA
LTE-FDD B20 @22.7dBm
157
mA
LTE-FDD B25 @23dBm
165
mA
LTE-FDD B26 @TBD
TBD
mA
LTE-FDD B28 @22.5dBm
163
mA
GPRS Data
Transfer
(GNSS OFF)
GSM850 4UL 1DL @30.17dBm
575
mA
GSM850 3UL 2DL @32dBm
533
mA
GSM850 2UL 3DL @32.74dBm
402
mA
GSM850 1UL 4DL @32.52dBm
220
mA
EGSM900 4UL 1DL @30.54dBm
586
mA
EGSM900 3UL2DL @31.36dBm
556
mA
EGSM900 2UL 3DL @32.62dBm
399
mA
EGSM900 1UL 4DL @32.75dBm
228
mA
DCS1800 4UL 1DL @29.81dBm
543
mA
DCS1800 3UL 2DL @30.09dBm
426
mA
