LTE Standard Module Series
EG91 Series Hardware Design
EG91_Series_Hardware_Design 82 / 106
EGSM900 33dBm±2dB 5dBm±5dB
DCS1800 30dBm±2dB 0dBm±5dB
PCS1900 30dBm±2dB 0dBm±5dB
GSM850 (8-PSK) 27dBm±3dB 5dBm±5dB
EGSM900 (8-PSK) 27dBm±3dB 5dBm±5dB
DCS1800 (8-PSK) 26dBm±3dB 0dBm±5dB
PCS1900 (8-PSK) 26dBm±3dB 0dBm±5dB
WCDMA B1/B2/B4/B5/B8 24dBm+1/-3dB < -49dBm
LTE-FDD B1/B2/B3/B4/B5/B7/
B8/B12/B13/B20/B25/B26/B28/B66
23dBm±2dB < -39dBm
In GPRS 4 slots TX mode, the maximum output power is reduced by 3.0dB. The design conforms to the
GSM specification as described in Chapter 13.16 of 3GPP TS 51.010-1.
6.6. RF Receiving Sensitivity
The following tables show the conducted RF receiving sensitivity of EG91 series module.
Table 42: EG91-E Conducted RF Receiving Sensitivity
Frequency
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
EGSM900 -108.6dBm NA NA -102dBm
DCS1800 -109.4 dBm NA NA -102dbm
WCDMA B1 -109.5dBm -110dBm -112.5dBm -106.7dBm
WCDMA B8 -109.5dBm -110dBm -112.5dBm -103.7dBm
LTE-FDD B1 (10MHz) -97.5dBm -98.3dBm -101.4dBm -96.3dBm
NOTE
