LTE-A Module Series
EM06 Series Hardware Design
EM06_Series_Hardware_Design 11 / 69
2 Product Concept
2.1. General Description
The EM06 series modules are a series of LTE-A/UMTS/HSPA+ wireless communication modules
featuring receive diversity. With standard PCI Express M.2 interfaces, the series supports data connection
on LTE-FDD, LTE-TDD, DC-HSDPA, DC-HSPA+, HSDPA, HSUPA and WCDMA networks.
EM06 series supports embedded operating systems such as Windows, Linux and Android, and also
carries GNSS
1)
and voice functionality
2)
to meet specific application demands. It contains three variants:
EM06-E, EM06-J and EM06-A. You can select a dedicated type based on your region or operator(s).
The following table lists the frequency bands, CA combinations and GNSS types supported by the
module.
Table 1: Frequency Bands, CA Combinations and GNSS Types Supported
