Quectel EM06 Series User Manual

LTE-A Module Series
EM06 Series Hardware Design
EM06_Series_Hardware_Design 41 / 69
Table 18: Pin Definition of Antenna Tuner Control Interface
“*” means under development.
3.12. Configuration Pins
The module provides four configuration pins which are configured as WWAN-USB.
Table 19: Definitions of Configuration Pins
The four pins on the module are defined as below:
Table 20: List of Configuration Pins
Pin Name
Pin No.
I/O
Description
Comment
ANTCTL0
59
DO
Antenna tuner control
1.8 V power domain
ANTCTL1
61
DO
Antenna tuner control
1.8 V power domain
ANTCTL2
63
DO
Antenna tuner control
1.8 V power domain
ANTCTL3
65
DO
Antenna tuner control
1.8 V power domain
Pin No.
Pin Name
I/O
Power Domain
Description
21
CONFIG_0
0
Connected to GND internally.
69
CONFIG_1
0
Connected to GND internally.
75
CONFIG_2
0
NC
1
CONFIG_3
0
NC
Config_0
(Pin 21)
Config_1
(Pin 69)
Config_2
(Pin 75)
Config_3
(Pin 1)
Module Type and
Main Host Interface
Port
Configuration
GND
GND
NC
NC
WWAN-USB
2
NOTE
