Quectel EM06 Series User Manual

LTE-A Module Series
EM06 Series Hardware Design
EM06_Series_Hardware_Design 3 / 69
About the Document
Revision History
Version
Date
Author
Description
1.0
2018-07-17
King MA/
Wison HE
Initial
1.1
2019-10-31
Jared WANG/
Jeremy LI
1. Updated CA feature of EM06-A (Table 1).
2. Updated Internet protocol features of EM06 (Table
2).
3. Deleted information about USB 3.0 and changed
USB 3.0 pins into NC pins (Figure 2 and Table 4).
4. Added operating modes (Chapter 3.3)
5. Added GNSS performance (Chapter 4.2)
6. Updated EM06-A current consumption (Table 35).
Added EM06-A conducted RF receiving sensitivity
(Table 39).
7. Variant EM06-A, function DFOTA and dual SIM
single standby have been fully developed.
1.2
2019-11-11
Jeremy LI
1. Updated GNSS performance (Table 21).
2. Updated the reference circuit of (U)SIM interface
with normally closed (U)SIM card connector (Figure
13) and the reference circuit of (U)SIM interface with
normally open (U)SIM card connector (Figure 14).
1.3
2020-09-07
Jada LIN/
Jerax KONG
1. Updated the definition of
FULL_CARD_POWER_OFF# (Table 7).
2. Updated the timing of turning on module (Figure 8)
and the timing of turning off the module through
FULL_CARD_POWER_OFF# (Figure 9).
3. Added the timing of (U)SIM (Figure 16) and the
timing of hot-plug (Figure 17).
4. Deleted the information about active antenna (Table
26).
