LTE-A Module Series
EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 13 / 82
1.
1)
For LTE FDD Band 3, the transmitting power is 21.5 dBm ±1 dB.
2.
2)
DC-HSDPA can be used, but the throughput speed and connection stability has yet to be optimized.
3.
3)
Within operating temperature range, the module is 3GPP compliant.
4.
4)
Within extended temperature range, the module keeps the ability to establish and maintain a voice,
SMS, data transmission, emergency call, etc. There won’t be unrecoverable malfunctions. Nor will
there be effects on the radio spectrum or harm to radio networks. Only one or more parameters like
P
out
might reduce in the value and exceed specified tolerances. When the temperature returns to
normal operation temperature levels, the module will meet 3GPP specifications again.
5. It is not recommended to use the module without adopting a heat dissipation component. Tests are
Compliant with USB 2.0 specifications, with maximum transmission rates
up to 480 Mbps on USB 2.0.
Used for AT command communication, data transmission, firmware
upgrade, software debugging.
Support USB serial drivers for: Windows 7/8/8.1/10;
WinCE 5.0/6.0/7.0*; Linux 2.6/3.x/4.1–4.14; Android 4.x/5.x/6.x/7.x/8.x
Main UART:
Used for AT command communication and data transmission
Baud rate reaches up to 921600 bps, 115200 bps by default
Support RTS and CTS hardware flow control
Debug UART:
Used for Linux console and log output
115200 bps baud rate
Comply with PCI Express Specification Revision 1.0
Used for Ethernet or WLAN communication
Compliant with 3GPP TS 27.007, 3GPP TS 27.005 and Quectel enhanced
AT commands
Two pins including NET_MODE and NET_STATUS to indicate network
connectivity status
Including the main antenna interface (ANT_MAIN) and Rx-diversity
antenna interface (ANT_DRX)
Size: (37.0 ±0.2) mm × (39.5 ±0.2) mm × (3.05 ±0.2) mm
Weight: approx. 6.7 g
Operating temperature range: -20 °C to +55 °C
3)
Extended temperature range: -25 °C to +60 °C
4)
Storage temperature range: -40 °C to +90 °C
All hardware components are fully compliant with EU RoHS directive
