LTE-A Module Series
EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 63 / 82
5 Electrical, Reliability and Radio
Characteristics
5.1. Absolute Maximum Ratings
Absolute maximum ratings for power supply and voltage on digital and analog pins of the module are
listed in the following table.
Table 30: Absolute Maximum Ratings
1)
The current consumption is tested in 3G/4G instead of 2G environment.
Item
Min.
Max.
Unit
VBAT_RF/VBAT_BB
-0.3
4.7
V
USB_VBUS
-0.3
5.5
V
Peak Current of VBAT_BB
0
1.5
A
Peak Current of VBAT_RF
0
0.3
1)
A
Voltage at Digital Pins
-0.3
2.3
V
Voltage at ADC0
0
1.4
V
Voltage at ADC1
0
1.4
V
NOTE
