Quectel LTE-A Series User Manual

LTE-A Module Series
EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 21 / 82
hot-plug detect
V
IL
max = 0.6 V
V
IH
min = 1.2 V
V
IH
max = 2.0 V
If unused, keep it
open.
Main UART Interface
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
MAIN_RI
61
DO
Main UART ring
indication
V
OL
max = 0.45 V
V
OH
min = 1.35 V
1.8 V power domain.
If unused, keep it
open.
MAIN_DCD
59
DO
Main UART data
carrier detect
V
OL
max = 0.45 V
V
OH
min = 1.35 V
1.8 V power domain.
If unused, keep it
open.
MAIN_CTS
56
DO
Main UART clear
to send
V
OL
max = 0.45 V
V
OH
min = 1.35 V
1.8 V power domain.
If unused, keep it
open.
MAIN_RTS
57
DI
Main UART
request to send
V
IL
min = -0.3 V
V
IL
max = 0.6 V
V
IH
min = 1.2 V
V
IH
max = 2.0 V
1.8 V power domain.
If unused, keep it
open.
MAIN_DTR
62
DI
Main UART data
terminal ready
V
IL
min = -0.3 V
V
IL
max = 0.6 V
V
IH
min = 1.2 V
V
IH
max = 2.0 V
1.8 V power domain.
Pull-up by default.
Pulling down to low
level will wake up the
module.
If unused, keep it
open.
MAIN_TXD
60
DO
Main UART
transmit
V
OL
max = 0.45 V
V
OH
min = 1.35 V
1.8 V power domain.
If unused, keep it
open.
MAIN_RXD
58
DI
Main UART
receive
V
IL
min = -0.3 V
V
IL
max = 0.6 V
V
IH
min = 1.2 V
V
IH
max = 2.0 V
1.8 V power domain.
If unused, keep it
open.
Debug UART Interface
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
DBG_RXD
136
DI
Debug UART
receive
V
IL
min = -0.3 V
V
IL
max = 0.6 V
V
IH
min = 1.2 V
V
IH
max = 2.0 V
1.8 V power domain.
If unused, keep it
open.
DBG_TXD
137
DO
Debug UART
transmit
V
OL
max = 0.45 V
V
OH
min = 1.35 V
1.8 V power domain.
If unused, keep it
