2 Product Overview
2.1. Frequency Bands and Functions
SC206E series is a series of Smart LTE modules based on Linux operating system, and provides
industrial grade performance. Its general features are listed below:
⚫ Supports worldwide LTE-FDD, LTE-TDD, DC-HSDPA, HSPA+, HSDPA, HSUPA, WCDMA,
EV-DO/CDMA, EDGE and GPRS coverage.
⚫ Supports short-range wireless communication via Wi-Fi 802.11a/b/g/n/ac and Bluetooth 5.0
1
.
⚫ Integrates GPS/GLONASS/BDS/Galileo/QZSS/SBAS/NavIC satellite positioning systems.
⚫ Supports multiple audio and video codecs.
⚫ Built-in high performance Adreno
TM
702 graphics processing unit.
⚫ Provides multiple audio and video input/output interfaces as well as abundant GPIO interfaces.
The module is available in four variants: SC206E-CE, SC206E-EM, SC206E-NA, SC206E-WF. The
following tables show the supported frequency bands and network standards of the module.
Table 2: SC206E-CE Frequency Bands and GNSS Functions
1
The module is compliant with all mandatory Bluetooth 5.0 features, but does not support Bluetooth 5.0 optional features
like 2 Mbps BLE, Advanced Advertising Extension, etc.
Mode
Frequency Bands
LTE-FDD
B1/B3/B5/B8
LTE-TDD
B34/B38/B39/B40/B41
WCDMA
B1/B8
EV-DO/CDMA
BC0
GSM
EGSM900/DCS1800
Wi-Fi 802.11a/b/g/n/ac
2402–2482 MHz
5180–5825 MHz
