Smart Module Series
SC206E_Series_Hardware_Design 18 / 115
Table 5: SC206E-WF Frequency Bands and GNSS Functions
The module is a series of SMD type modules, which can be embedded into applications through its 274
pins, including 146 LCC pins and 128 LGA pins. With a compact profile of 40.5 mm × 40.5 mm × 2.85
mm, the module can meet most of the requirements for M2M applications such as edge device, edge
computing, CPE, wireless POS, smart metering, router, data card, automotive, smart phone, digital
signage, alarm panel, security and industry PDA, etc.
2.2. Key Features
The following table describes the detailed features of the module.
Table 5: Key Features
⚫ 1575.42 ±1.023 MHz (L1)
⚫ 1176.45 ±10.23 MHz (L5)
GLONASS: 1597.5–1605.8 MHz (L1)
BDS: 1561.098 ±2 .046 MHz (B1I)
Galileo:
⚫ 1575.42 ±2.046 MHz (E1)
⚫ 1176.45 ±10.23 MHz (E5a)
QZSS:
⚫ 1575.42 ±1.023 MHz (L1)
⚫ 1176.45 ±10.23 MHz (L5)
SBAS:
⚫ 1575.42 ±1.023 MHz (L1)
⚫ 1176.45 ±10.23 MHz (L5)
NavIC: 1176.45 ±10.23 (L5)
