Quectel SC206E Series User Manual

Smart Module Series
SC206E_Series_Hardware_Design 53 / 115
3.15. ADC Interface
The module supports one Analog-to-Digital Converter (ADC) interface. The ADC interface supports
resolution of up to 15 bits. The pin definition is shown below.
Table 18: Pin Definition of ADC Interface
3.16. Motor Drive Interface
The pin definition of the motor drive interface is listed below.
Table 19: Pin Definition of Motor Drive Interface
TP_I2C_SDA
48
OD
TP I2C data
1.8 V externally. Can be
used for other I2C
devices.
CAM0_I2C_SCL
83
OD
I2C clock of camera 0
Can only be used for
camera I2C devices.
CAM0_I2C_SDA
84
OD
I2C data of camera 0
CAM1_I2C_SCL
166
OD
I2C clock of camera 1
CAM1_I2C_SDA
205
OD
I2C data of camera 1
SENSOR_I2C_SCL
91
OD
I2C clock for external sensor
Can only be used to for
sensors.
SENSOR_I2C_SDA
92
OD
I2C data for external sensor
Pin Name
Pin No.
I/O
Description
Comment
ADC
128
AI
General-purpose ADC interface
The maximum input voltage is 1.875 V.
Pin Name
Pin No.
I/O
Description
Comment
VIB_DRV_P
28
PO
Vibration motor driver
output control
Connect it to the positive pole of the motor.
