In GPRS and EDGE 4-slot Tx mode, the maximum output power is reduced by 3 dB. This design
conforms to the GSM specification as described in 3GPP TS 51.010-1 subclause 13.16 and subclause
13.17.
7.7. Rx Sensitivity
The following table shows the RF receiving sensitivity of the module.
Table 56: SC206E-CE RF Rx Sensitivity
Table 57: SC206E-EM RF Rx Sensitivity
Frequency Bands
Receiving Sensitivity (dBm) (Typ.)
3GPP (SIMO)
Primary
Diversity
SIMO
EGSM900
-109.5
-
-
-102.4
DCS1800
-109
-
-
-102.4
WCDMA B1
-110.5
-112
TBD
-106.7
WCDMA B8
-111
-112
TBD
-103.7
EV-DO/CDMA BC0
-108.5
-
-
-104
LTE-FDD B1 (10 MHz)
-98
-100
-102
-96.3
LTE-FDD B3 (10 MHz)
-98.5
-98.5
-101.5
-93.3
LTE-FDD B5 (10 MHz)
-99.5
-99.5
-102.5
-94.3
LTE-FDD B8 (10 MHz)
-99
-100
-102.5
-93.3
LTE-TDD B34 (10 MHz)
-98
-99
-101.5
-96.3
LTE-TDD B38 (10 MHz)
-97
-98
-99.6
-96.3
LTE-TDD B39 (10 MHz)
-98
-99
-101.5
-96.3
LTE-TDD B40 (10 MHz)
-97.5
-98.5
-101
-96.3
LTE-TDD B41 (10 MHz)
-96
-98
-99.5
-94.3
Frequency Bands
Receiving Sensitivity (dBm) (Typ.)
3GPP (SIMO)
Primary
Diversity
SIMO
