Page #72 background image
Smart Module Series
SC206E_Series_Hardware_Design 71 / 115
The BR/EDR channel bandwidth is 1 MHz, and can accommodate 79 channels. The BLE channel
bandwidth is 2 MHz, and can accommodate 40 channels.
Table 30: Bluetooth Data Rate and Version
Reference specifications are listed below:
Bluetooth Radio Frequency TSS and TP Specification 1.2/2.0/2.0 + EDR/2.1/2.1 + EDR/3.0/3.0 +
HS, August 6, 2009
Bluetooth Low Energy RF PHY Test Specification, RF-PHY.TS/4.0.0, December 15, 2009
4.2.1. Bluetooth Performance
The following table lists the Bluetooth transmitting and receiving performance of the module.
Table 31: Bluetooth Transmitting and Receiving Performance
Version
Data Rate
Maximum Application Throughput
1.2
1 Mbit/s
> 80 kbit/s
2.0 + EDR
3 Mbit/s
> 80 kbit/s
3.0 + HS
24 Mbit/s
Reference 3.0 + HS
4.0
24 Mbit/s
Reference 4.0 LE
5.0
24 Mbit/s
Reference 5.0 LE
Transmitter Performance
Packet Types
DH5
2-DH5
3-DH5
Transmitting Power
7 dBm ±3 dB
6.5 dBm ±3 dB
6.5 dBm ±3 dB
Receiver Performance
Packet Types
DH5
2-DH5
3-DH5
Receiving Sensitivity
-93 dBm
-93 dBm
-86 dBm
