Quectel SG368Z Series

Smart Module Series
SG368Z_Series_Hardware_Design 31 / 113
PMU_32K_CLK
150
OD
PMU 32 kHz clock
output
Only SG368Z-AP
supports this pin.
32K_CLK
165
DO
32 kHz clock output
VCCIO4
Only SG368Z-AP
supports this pin.
PWM4
55
DO
PWM output 4
PMUIO2
GPIO
Pin Name
Pin No.
I/O
Description
DC
Characteristics
Comment
GPIO0_D3
125
DIO
General-purpose
input/output
PMUIO0
GPIO0_D4
60
DIO
General-purpose
input/output
PMUIO0
GPIO0_D5
80
DIO
General-purpose
input/output
PMUIO0
GPIO0_D6
10
DIO
General-purpose
input/output
PMUIO0
GPIO0_A5
123
DIO
General-purpose
input/output
PMUIO1
GPIO0_B0
225
DIO
General-purpose
input/output
PMUIO2
Only SG368Z-AP
supports this pin.
GPIO0_B7
220
DIO
General-purpose
input/output
PMUIO2
Only SG368Z-AP
supports this pin.
GPIO0_C0
215
DIO
General-purpose
input/output
PMUIO2
Only SG368Z-AP
supports this pin.
GPIO0_C1
50
DIO
General-purpose
input/output
PMUIO2
Only SG368Z-AP
supports this pin.
GPIO0_C4
25
DIO
General-purpose
input/output
PMUIO2
GPIO0_C5
210
DIO
General-purpose
input/output
PMUIO2
Only SG368Z-AP
supports this pin.
GPIO0_C6
370
DIO
General-purpose
input/output
PMUIO2
GPIO0_C7
209
DIO
General-purpose
input/output
PMUIO2
Only SG368Z-AP
supports this pin.
GPIO1_D0
276
DIO
General-purpose
input/output
VCCIO2
GPIO1_D1
267
DIO
General-purpose
input/output
VCCIO2
GPIO1_D2
272
DIO
General-purpose
input/output
VCCIO2
GPIO1_D3
281
DIO
General-purpose
input/output
VCCIO2
