Quectel SG368Z Series User Manual

Smart Module Series
SG368Z_Series_Hardware_Design 32 / 113
GPIO1_D4
277
DIO
General-purpose
input/output
VCCIO2
GPIO2_C5
170
DIO
General-purpose
input/output
VCCIO4
Only SG368Z-AP
supports this pin.
GPIO3_A2
359
DIO
General-purpose
input/output
VCCIO5
GPIO3_A3
354
DIO
General-purpose
input/output
VCCIO5
GPIO3_A4
352
DIO
General-purpose
input/output
VCCIO5
GPIO3_A5
351
DIO
General-purpose
input/output
VCCIO5
GPIO3_A6
346
DIO
General-purpose
input/output
VCCIO5
GPIO3_A7
347
DIO
General-purpose
input/output
VCCIO5
GPIO3_B0
348
DIO
General-purpose
input/output
VCCIO5
GPIO3_B3
343
DIO
General-purpose
input/output
VCCIO5
GPIO3_B4
342
DIO
General-purpose
input/output
VCCIO5
GPIO3_B5
336
DIO
General-purpose
input/output
VCCIO5
GPIO3_B6
337
DIO
General-purpose
input/output
VCCIO5
GPIO3_C6
321
DIO
General-purpose
input/output
VCCIO6
GPIO3_D0
318
DIO
General-purpose
input/output
VCCIO6
GPIO3_D1
319
DIO
General-purpose
input/output
VCCIO6
GPIO4_B2
291
DIO
General-purpose
input/output
VCCIO6
GPIO4_D2
384
DIO
General-purpose
input/output
VCCIO7
RESERVED Pins
Pin Name
Pin No.
RESERVED
15, 20, 130, 135, 140, 192, 197, 198, 201, 204, 205, 208, 214, 219, 229, 230,
234, 239, 240, 244, 245, 249, 250, 254, 255, 260, 264, 265, 269, 270, 275, 299,
315, 320, 329, 330, 335, 340, 345, 360, 365, 377, 381
