Quectel Smart EVB G2 User Manual

Smart LTE Module Series
Smart EVB G2 User Guide
Smart_EVB_G2_User_Guide Confidential / Released 37 / 59
USB_DP
100nF
Module
C14
Switch
C2
C3
C4
C5
A0+
A0-
A1+
A1-
B0+
B0-
B1+
B1-
C0+
C0-
C1+
C1-
PD
USB_SS_TX_P
USB_SS_TX_M
USB_SS_RX_P
USB_SS_RX_M
R1
VDD_5V
4.7uF
C1
TX1+
TX1-
VBUS_VBUS
CC1
D+
D-
RX1-
RX1+
CC2
TX2+
TX2-
RX2+
RX2-
USB Type-C
C6
C7
C8
C9
C10
C11
C12
C13
USB_DM
USB_VBUS
USB_VCONN
CC1
CC2
USB_ID
ID_SW
VDD_3V3
VDD_3V3
DET
GND
DC
Adapter
DC 5V
Figure 24: Reference Circuit Design for USB Type-C Interface
1. USB super-speed switch IC is powered by DC adapter. So if customers want to use USB 3.0 interface
or USB OTG function, the module serves as the host device and the DC adapter must be plugged in.
2. If customers want to use USB 2.0 interface only, the module serves as the slave device. The DC
adapter can be removed and the power supply for super-speed switch IC is not needed.
Super-speed
switch IC
USB Type-C
Figure 25: USB Type-C Interface
NOTES
Quectel
Confidential
