UMTS/HSPA Module Series

UC20 Hardware Design

UC20_Hardware_Design Confidential / Released 12 / 82

UC20 is an SMD type module, which can be embedded in application through its 112-pin pads including

72 LCC signal pads and 40 other pads.

UC20 is integrated with internet service protocols like TCP/UDP and PPP. Extended AT commands have

been developed for customer to use these internet service protocols easily.

2.2. Key Features

The following table describes the detailed features of UC20 module.

Table 2: UC20 Key Features

Feature

Details

Power Supply

Supply voltage: 3.3V~4.3V

Typical supply voltage: 3.8V

Frequency Bands

UC20-A: UMTS850/1900

UC20-E: GSM850/900/1800/1900, UMTS900/2100

UC20-G: GSM850/900/1800/1900, UMTS800/850/900/1900/2100

Transmission Data

HSPA R6: Max 14.4Mbps (DL)/Max 5.76Mbps (UL)

UMTS R99: Max 384kbps (DL)/Max 384kbps (UL)

EDGE: Max 236.8kbps (DL)/Max 236.8kbps (UL)

GPRS: Max 85.6kbps (DL)/Max 85.6kbps (UL)

CSD: 14.4kbps

Transmitting Power

Class 4 (33dBm±2dB) for GSM850 and EGSM900

Class 1 (30dBm±2dB) for DCS1800 and PCS1900

Class E2 (27dBm±3dB) for GSM850 and EGSM900 8-PSK

Class E2 (26dBm+3/-4dB) for DCS1800 and PCS1900 8-PSK

Class 3 (24dBm+1/-3dB) for UMTS800/850/900/1900/2100

HSPA and UMTS Features

HSPA data rate is corresponded with 3GPP R6. 14.4Mbps on downlink

and 5.76Mbps on uplink.

WCDMA data rate is corresponded with 3GPP R99/R4. 384kbps on

downlink and 384kbps on uplink.

Support both 16-QAM and QPSK modulation.

GSM/GPRS/EDGE

Data Features

GPRS:

Support GPRS multi-slot class 12 (10 by default)

Coding scheme: CS-1, CS-2, CS-3 and CS-4

Maximum of four Rx time slots per frame

EDGE:

Support EDGE multi-slot class 12 (12 by default).

Support GMSK and 8-PSK for different MCS (Modulation and Coding
