4.2. GNSS Performance
The following table shows UC20 GNSS performance.
Table 22: GNSS Performance
Parameter
Description
Conditions
Typ.
Unit
Sensitivity
(GNSS)
Cold start
Autonomous
-144
dBm
With LNA
-147
dBm
Reacquisition
Autonomous
-154
dBm
With LNA
-159
dBm
Tracking
Autonomous
-155
dBm
With LNA
-161
dBm
TTFF
(GNSS)
Cold start
@open sky
Autonomous
32
s
XTRA enabled
22
s
Warm start
@open sky
Autonomous
29
s
XTRA enabled
3
s
Hot start
@open sky
Autonomous
2.5
s
XTRA enabled
2
s
Accuracy
(GNSS)
CEP-50
Autonomous
@open sky
<1.5
m
1. Tracking sensitivity: the lowest GPS signal value at the antenna port for which the module can keep
on positioning for 3 minutes.
2. Reacquisition sensitivity: the lowest GPS signal value at the antenna port for which the module can
fix position again within 3 minutes after loss of lock.
3. Cold start sensitivity: the lowest GPS signal value at the antenna port for which the module fixes
position within 3 minutes after executing cold start command.
