2 Product Concept
2.1. General Description
UC200T-GL Mini PCIe module provides data connectivity on DC-HSDPA, HSPA+, HSDPA, HSUPA,
WCDMA, TD-SCDMA, EVDO, CDMA, EDGE and GPRS networks with PCI Express Mini Card 1.2
standard interface. It provides audio and high-speed data transmission for customers’ applications.
UC200T-GL Mini PCIe module can be applied in the following fields:
 PDA and Laptop Computer
 Remote Monitor System
 Vehicle System
 Wireless POS System
 Intelligent Meter Reading System
 Wireless Router and Switch
 Other Wireless Terminal Devices
Table 1: Supported Bands of UC200T-GL Mini PCIe
2.2. Key Features
The following table describes the detailed features of UC200T-GL Mini PCIe module.
Table 2: Key Features of UC200T-GL Mini PCIe
Module Description
UC200T-GL Mini PCIe
WCDMA: B1/B8
TD-SCDMA: B34/B39
EVDO/CDMA: BC0
GSM: 900/1800MHz
Support digital audio
3)
Features Description

Quectel UC200T-GL Specifications

General

Brand	Quectel
Model	UC200T-GL
Category	Control Unit
Language	English
