Quectel UC200T-GL Hardware Design

UMTS/HSPA+ Standard Module Series
UC200T-GL Mini PCIe Hardware Design
UC200T-GL_Mini_PCIe_Hardware_Design 17 / 51
3.2. Pin Description
The following tables show the pin definition and description of the 52 pins on UC200T-GL Mini PCIe.
Table 3: I/O Parameters Definition
Table 4: Pin Description
Type Description
DI Digital Input
DO Digital Output
IO Bidirectional
OC Open Collector
PI Power Input
PO Power Output
Pin No.
Mini PCI Express
Standard Name
UC200T-GL Mini
PCIe Pin Name
I/O Description Comment
1 WAKE# WAKE# OC
Output signal used to
wake up the host.
2 3.3Vaux VCC_3V3 PI
3.0V~3.6V, typically 3.3V
DC supply
3 RESERVED RESERVED Reserved
4 GND GND Mini card ground
5 RESERVED RESERVED Reserved
6 1.5V NC Not connected
7 CLKREQ# RESERVED Reserved
8 UIM_PWR USIM_VDD PO
Power supply for the
(U)SIM card
9 GND GND Mini card ground
10 UIM_DATA USIM_DATA IO
Data signal of (U)SIM
card
