Quectel UC200T-GL - Page 41

UMTS/HSPA+ Standard Module Series
UC200T-GL Mini PCIe Hardware Design
UC200T-GL_Mini_PCIe_Hardware_Design 40 / 51
TD-SCDMA Band F @23.42dBm mA
WCDMA
data transfer
(GNSS OFF)
WCDMA B1 HSDPA @22.03dBm mA
WCDMA B1 HSUPA @22.02dBm mA
WCDMA B8 HSDPA @21.68dBm mA
WCDMA B8 HSUPA @21.75dBm mA
GSM
voice call
EGSM900 PCL=5 @32.47dBm mA
EGSM900 PCL=12 @19.40dBm mA
EGSM900 PCL=19 @5.58dBm mA
DCS1800 PCL=0 @29.49dBm mA
DCS1800 PCL=7 @16.47dBm mA
DCS1800 PCL=15 @0.24dBm mA
CDMA
voice call
BC0 @23.87dBm mA
BC0 @-60.67dBm mA
WCDMA
voice call
WCDMA B1 @23.05dBm mA
WCDMA B8 @23.1dBm mA
Table 24: GNSS Current Consumption of UC200T-GL Mini PCIe
Parameter Description Conditions Typ. Unit
I
VBAT
(GNSS)
Searching
(AT+CFUN=0)
Cold start @Passive Antenna mA
Lost state @Passive Antenna mA
Tracking
(AT+CFUN=0)
Instrument Environment mA
Open Sky @Passive Antenna mA
Open Sky @Active Antenna mA
