Quest Engineering Q30 User Manual

5
1. Put the end of the sha with the hole
into the search coil like shown in 1.
2. Insert the screw into the hole as
shown in 2 and secure by ghtening the
nut.
1
2
Open the camlock on the middle
sha and insert the lower sha with
the search coil, as shown in 3. When
the sha is in the right posion,
close the camlock.
3
3. Assembly
