Quicksilver 755PH — System & Component Overview and Operaon
Bow Thruster
Thruster
Baery
Baery switch
150A Fuse
Control panel
Before operang the windlass, make sure that the safety
lanyard is removed from the anchor .
12. Bow Thruster (oponal)
The electric bow thruster assists with the maneuvering of your vessel when docking. Access to the
motor is via the interior liner footwell hatch, access to the baery is via the liner oor forward hatch
and baery switch is located under the liner port seat riser hatch.
Operaon
To operate the thruster, you rst must turn the thruster baery switch to the ON posion. At the
helm, press the on/o switch on the control panel. An LED will ash and a buzzer will sound
connuously. Press the on/o switch again within 6 seconds . The system will conrm that it is ready
for use when the LED light remains green and the buzzer sounds twice.
To move the bow to the port direcon, move the joysck to the le. To move the bow to the
starboard direcon, move the joysck to the right. Refer to the thruster owner’s manual for complete
details on the operaon and warranty informaon. To turn o the bow thruster controls, press the
on/o switch once.
REFER TO OWNER’S MANUAL PACKAGE FOR INSTRUCTIONS AND WARRANTY INFORMATION.
and lower the anchor. Pushing down on the switch will lower the anchor, while pushing up on the
switch raises the anchor. Similarly, using the handheld remote control key FOB, pushing on the down
switch will lower the anchor, while pushing the up on the switch will raise the anchor.
Built in to the stern windlass is an auto stop funcon that shuts the motor o once the anchor is fully
retracted and in the stored posion on the anchor roller. Mounted on the transom, the leaded core
rope goes through a mounng plate containing sensors. A red auto stop located at the end of the
rope will automacally shut the windlass o when it comes in contact with the sensors in the
mounng plate.
REFER TO OWNER’S MANUAL PACKAGE FOR INSTRUCTIONS AND WARRANTY INFORMATION.
