Quicksilver 755PH — System & Component Overview and Operaon
16. SmartCra
TM
System Gauges
The instrument package on your boat includes a SmartCra
TM
tachometer and speedometer mul-
gauge system. By pressing the “mode” buon on the gauge, specic informaon vital to the safe
operaon of the vessel can be displayed. Refer to your SmartCra
TM
gauge owner’s manual for
specic informaon on how to get the most out of the mul-gauge display.
17. Trim Tabs (oponal)
The trim tabs are located within recesses in the hull at the transom and are used to level the boat
(port to starboard) caused by uneven weight distribuon, too many people on one side of the vessel,
or by strong winds pushing the vessel to one side.
The trim tabs are controlled by switches located at the helm. LED indicators located on the switch
indicate the amount of trim tab deecon (one bar indicates trim tabs are in the up posion, while all
red bars indicate the trim tabs are fully deployed in the down posion). To lower the port bow (boat is
running with a starboard list), push the le switch marked DOWN. Alternavely, to lower the
starboard bow (boat is running with a port list), push the right switch marked DOWN.
REFER TO OWNER’S MANUAL PACKAGE FOR INSTRUCTIONS AND WARRANTY INFORMATION.
Trim tab switch
Trim tab control box
Trim tab harness
Trim tab cylinder
Trim tab plate
Zinc anode
Trim Tabs
18. Exterior Helm (oponal)
An oponal exterior helm is available which allows for low speed operaon of your boat while in the
cockpit. The exterior helm, located on the forward starboard side of the cockpit consists of a steering
wheel, a hydraulic helm pump, a remote control, and an emergency engine shutdown switch.
Depending on the engine installed on your boat, you will either have a mechanical gear shi/throle
control unit or a “drive by wire” Digital Throle and Shi (DTS®) control unit. The control unit, located
to the port side of the steering wheel, acvates both the shiing and throle for the engine.
