Quicksilver 755PH — System & Component Overview and Operaon
40
Dual Helm Hydraulic Steering
Dual Helm, L6 Verado Steering
Steering wheel
Main helm pump
Hydraulic uid lines
Exterior helm pump
Power assist pump
Maintenance
A hydraulic steering system rarely needs to be relled aer the system is bled. However, if you ever
need to add uid to the system, refer to the steering manufacturer’s manual for complete
instrucons.
On a standard helm (non–L6 Verado), the ll is located on the top of the helm pump. If you need to
add uid to the system, you must add the uid at the exterior helm, not the main helm. On a six
cylinder Verado powered boat, uid is added at the power assist pump.
REFER TO OWNER’S MANUAL PACKAGE FOR INSTRUCTIONS AND WARRANTY INFORMATION.
19. Diesel Heat (oponal)
The diesel heat system consists of a 4kW heater, a 10L diesel tank providing fuel for the heater, and a
control panel that runs the system.
Steering wheel
Main helm pump
Hydraulic uid lines
Exterior helm pump
Steering cylinder
