GPS
SmartCra
TM
gauges
Stereo
12V outlet
USB receptacle
Helm switches
Steering wheel
Bow thruster control
Trim tab switches
Fire exnguisher override
Windlass switch
Trolling valve control
Engine throle shi control
10. Dash Layout
Please note that operator vision from the helm may be obstructed by high trim angles of the cra,
along with other factors such as hull trim plane angles, loading and load distribuon, speed & acceler-
aon, transion from displacement to planing mode, sea condions, rain and spray, darkness and fog,
interior lights, posion of tops and curtains, and persons or movable gear in the operator’s eld of
vision.
Dash Switch Panel
11. Navigaon Lights
Your boat comes equipped with navigaon lighng for use at night or in low visibility condions. Prior
to running at night, make sure that the all around light located on the hardtop is in the upright
posion. There are two switches, located on the helm switch panel, that controls these lights. To turn
on the Navigaon Lights, push the upper part of the le switch forward to illuminate the port (red)
and starboard (green) bow lights, and push the upper part of the right switch forward to illuminate
the all around light (white) showing other vessels that you are underway. To turn on the Anchor Light,
only push the upper part of the right switch illuminang the all around light (white), leng other
boaters know that you are anchored at a given locaon.
Bow navigaon lights
Anchor light
Lighng
Fresh water pump
Bilge pump
Bilge pump
Port wiper
Starboard wiper
