1. DC Electrical System
The DC electrical system is powered by a single baery, and is kept charged by the engine driven
alternator.
2. Baery
Refer to your engine owner’s manual for exact baery requirements.
To remove the baery cables:
1. Turn o all items drawing power from the baery.
2. Turn the baery switch to the OFF posion.
3. Remove the negave cable rst, then the posive cable.
4. To replace the cables, install the posive cable rst, then the negave cable.
3. Baery Box
The baery box, located in the a bilge, houses the baery. This box can be accessed via the cockpit
oor hatch. The baery can be installed or removed by loosening the straps and removing the lids on
the baery box. They should always be installed and secured within the baery box installed on your
boat. This will ensure that the baery will not move around while the boat is underway.
4. Baery Switch
Your vessel is equipped with a baery switch to control the delivery of DC power from the baery.
The baery switch is located in the a bilge. When you turn the baery switch to the ON posion,
power is provided from the baery to the enre boat. To turn on power, rotate the switch clockwise
90 degrees to the ON posion.
Never use an open ame in the baery storage area. Avoid
striking sparks in the baery area.
Always disconnect the baery before doing any work on the
electrical system. Never turn o the baery switches or
disconnect the baery cables while the engines are running.
Baery Switch Operaon
OFF Posion
ON Posion
The bilge pump sll draws power from the baery, even if
the switch is set to OFF. This is especially important for the
bilge pump, so that it can operate anyme excess uid
accumulates in the bilge, which can occur when the boat is
docked and unaended.
Never work on the electrical system while the system is
energized. Never leave the cra unaended with the
electrical system energized.
