Quicksilver 810 Arvor - Black Water System (optional)

13
Quicksilver 810 Arvor — System & Component Overview and Operaon
Fresh Water System
Water pump strainer
Water pump
Galley faucet hose
Galley faucet
Water tank ll
Water tank vent
Water tank vent hose
Water tank ll hose
Water tank
Water tank to water pump hose
3. Black Water System (oponal)
Your vessel may be equipped with a waste containment / disposal system. This includes a toilet
water pickup, manual ush toilet, a 80 liter holding tank, macerator, discharge seacock, and a
dockside pump out connecon.
There are two possible toilet conguraons. First, your boat could be equipped with a toilet located
under a cover with a cushion on the starboard side of the cabin, or the toilet could be in an enclosed
compartment located on the starboard side of the cabin.
Operaon
Prior to using the toilet, make sure that the toilet water pickup valve, located under the center liner
hatch, is opened. If your boat is equipped with the toilet located under a cover, remove the cushion
covering the toilet lid. Next, rotate the lid over the toilet and remove the inboard toilet wall,
exposing the toilet for use. When not in use, the forward toilet wall and toilet lid should be installed
in place, covering the toilet.
Refer to the toilet owner's manual in regards to specic operaon of the toilet. When ushing the
toilet, it will take approximately 19 complete up/down strokes for the contents to reach the holding
tank.
Macerator
The macerator gives the boat operator the means of discharging the holding tank directly
overboard through a seacock in the boom of the hull. The macerator switch is located inside the
