10. Stern Anchor Windlass (oponal)
The anchor windlass located at the stern of the boat assists with the anchoring of your boat by
automacally raising and lowering the anchor. The windlass is operated from the helm or by a
handheld remote control key FOB.
Operaon
To operate the windlass, the windlass breaker, located next to the baery switch in the a bilge, must
be turned ON. Operaon of the windlass at the helm is controlled by a momentary switch used to
raise and lower the anchor. Pushing down on the switch will lower the anchor, while pushing up on
the switch raises the anchor.
Built in to the stern windlass is an auto stop funcon that shuts the motor o once the anchor is fully
retracted and in the stored posion on the anchor roller. Mounted on the transom, the leaded core
rope goes through a mounng plate containing sensors. A red auto stop located at the end of the
rope will automacally shut the windlass o when it comes in contact with the sensors in the
mounng plate.
Stern Windlass
11. Bow Thruster
The electric bow thruster assists with the maneuvering of your vessel when docking. Access to the
motor and baery is via the forward berth storage area, while the baery switch is located under the
step in the interior cabin.
Operaon from the helm
To operate the thruster, you rst must turn the thruster baery switch to the ON posion. At the
helm, press the on/o switch on the control panel. An LED will ash and a buzzer will sound
Key FOB
Stern windlass
Stern eye
Stern anchor roller
Anchor
