Quicksilver 810 Arvor — System & Component Overview and Operaon
14
Black Water System
Overboard discharge
Holding tank to pumpout hose
Pumpout deck plate
Holding tank to vent lter hose
Vent lter
Vent lter to tank vent thru hull hose
Tank vent thru hull
Toilet water pickup
Pickup to toilet water hose
Toilet
Toilet to holding tank hose
Holding tank
Holding tank to macerator hose
Macerator
Macerator to overboard discharge hose
This boat is equipped with an overboard discharge seacock.
Some countries levy severe penales for discharging raw
sewage and solid waste in waters where it is prohibited. Be
aware of local environmental laws, and respect codes of
good pracce. Demonstrang that the macerator is disabled
by locking the system and/or removing the seacock handle
may avoid a ne.
The toilet water pickup valve should always be in the closed
posion when not in use. Failure to do so could result in
ooding, property damage, and/or loss of life.
cabin on the port pilaster. Since direct overboard discharge is prohibited in many areas, the macerator
seacock is normally closed.
To Operate the Macerator:
1. Make sure the macerator seacock is in the open posion.
2. Press and hold the macerator switch located on the main baery panel. The macerator switch
is a momentary switch, which means that it needs to be held in the “ON” posion during
operaon.
3. When the tank is empty, release the macerator switch.
4. Return the macerator seacock to the closed posion.
