Quicksilver 810 Arvor — System & Component Overview and Operaon
Tank Storage
The LPG tank storage is located in the starboard walkthrough. The tanks must be rmly secured to the
boat with the tanks in a horizontal posion. Do not relocate or reposion the tanks. Do not obstruct
access to the LPG tanks in any way. Make sure to keep valves on empty cylinders closed and
disconnected, and keep protecve covers, caps or plugs in place. Only keep spare cylinders in
venlated housings on open decks or in gas-ght lockers which are vented overboard and intended
for storing LPG tanks. Finally, do not use LPG cylinder housing for storage of any other equipment.
LPG Shuto Valve
An inline fuel shuto valve is located in the forward storage area in the galley. Always close fuel
supply line valves and cylinder valve when appliances are not in use. Also, remember to close all
valves before refueling and immediately in an emergency. Finally, be sure appliance valves are closed
before opening cylinder valve.
LPG Pipe & Hoses
Your LPG system consists of hoses connecng the LPG tank to the stove. The hoses in the LPG system
must be inspected regularly, at least annually, and replaced if any deterioraon is found.
LPG System LPG System
2kg LPG tank (not supplied)
Regulator (not supplied)
LPG tank hose
Tank to shuto valve hose
Shuto valve
Shuto valve to stove hose
Stove
LPG working pressure: Butane = 28mbar, Propane = 37mbar
