Instruction Book
9828 0934 73 35
2.5 Condensate drain system
Description
Electronic water drain location
Electronic water drain functioning
Reference
Name
1
Inlet
2
Supply line
3
Pilot valve
4
Diaphragm
5
Sensor
6
Collector
7
Valve seat
8
Outlet
