Instruction Book
48 9828 0934 73
Text on figure
(1)
Condensing pressure
(2)
Evaporating pressure
(3)
Dryer LAT 1
(4)
Refrigerant 1
• The screen shows the first items of a list of all inputs with their corresponding icons and readings.
Use the scroll button to see the other items in the list.
• If an input is in warning or shutdown, the original icon is replaced by the warning or shutdown
icon respectively.
3.7 Outputs menu
Control panel
(1)
Scroll keys
(2)
Enter key
(3)
Escape key
Menu icon, Outputs
